Battery Test

The company’s senior engineer team provides highly flexible one-stop testing and certification service solutions for battery manufacturers, battery distributors and importers to cooperate with customers to easily and conveniently obtain access to multi-country markets. At present, the battery laboratory is equipped with large-scale testing equipment and instruments, and provides testing and certification services for various battery products according to the relevant standards of major countries and regions such as the European Union and North America, so as to ensure that battery products meet the requirements of safety, performance, storage, transportation, chemistry and electromagnetic compatibility, and are a reliable partner of the battery industry. It is also a third-party responsible person for helping customers to enhance the competitiveness of their products and reduce the risks caused by the products themselves.

Battery service coverage

Transport safety testing International Certification
Safety certification EMC certification EMC testing
Chemical testingChernical testing Electrochemical testing
Technician use soldering iron to solder metal and wire of lithium-ion rechargeable battery. Repair module of Li-ion battery. Engineer hand holds soldering iron and tin-lead to solder electronic board.

Battery test standards

products       Certification program       Test Standards
battery         SDS        OSHA GHS New Edition
Portable secondary cells and batteries        CB       IEC/EN 62133
Portable secondary cells and batteries        Capacity       IEC/EN 61960
Lithium battery cells        UL/cTUVus/ETL/CSA       UL 1642/UL E62133/CSA E62133
Household and commercial batteries        UL/cTUVus/ETL/CSA       UL 2054/UL E62133/CSA E62133
Portable secondary lithium batteries and cells         KC       KC 62133/K 62133
Lithium battery        PSE       MITI(1962:No.85)1st Clause:Appendix 9
Lithium cells and batteries        TISI       TIS 2217-2548(2005)
Lithium batteries for cellular phones        ANATEL       Resolution #481
Lithium cells/batteries        Cu-TR/EAC       IEC 62133 EN61000-6-1/3
Lithium cells/batteries        NOM       NOM-001-SCFI-1993
battery        CE       EN55032 ,EN61000-6-1,EN61000-6-3
Battery/portable power bank         BIS       IS16046
battery        FCC       Part 15B
Portable secondary batteries and cells        BSMI       CNS 15364
Portable secondary battery cells and batteries        CQC or Report       GB 31241



Battery test items

1. Environmental testing

Low pressure
Temperature cycling
Thermal abuse

2. Mechanical testing

Vibration
Mechanical shock
Free fall
Squeeze Crush
Heavy Impact Impact

3. Electric Testing

Rated capacity Discharge performance
Over discharge Overcharge
Forced discharge High-rate charging
External short circuit Endurance
Internal resistance Charge retention and recovery

4. Electrostatic discharge test

5. EMC testing

6. Battery materials analysis

7. Analysis of battery material characteristics Electrochemical analysis
